20" X 26" Automatic Vertical Tilt Frame Band Saw Machine

Description

Band Saw Machine

Automatic Vertical Tilt-Frame Band Saw is vertical saw frame allows the user to cut at any angle between 90° (straight cut) and 60° (miter cut) in both directions. The precision pivot system facilitates easy and accurate adjustment for angle cuts. Angle changes are made through a manually actuated hydraulic system with digital angle display or can be programmed through the auto-cycle programming on the HMI. AV-2026NC requires no tools to make angle changes. Saw frame also has an adjustable cant from 0 to 5 degrees. Rigid and heavy-duty saw frame, bed and wheels provide for maximum vibration dampening and improved cutting performance.

Standard Features

• Hydraulic tilt-frame head allows miter cutting from 0 degrees to plus/minus 60 degrees.
• Adjustable head cant from 0 to 5 degrees.
• Gearbox designed to accept high lateral pressure (no thermal distortion).
• Inverter blade drive system which allows infinitely variable blade speeds.
• 10.1" HMI touchscreen.
• Adjustable flood coolant system.
• Motor driven, synchronized wire blade brush.
• Carbide blade guides and bearing provides additional blade support.
• Hydraulic blade tensioning device.
• Precision feed pressure and feed rate dual valve system for optimal cutting performance.
