320mm Round Automatic Horizontal Dual Column Type Band Saw

Description

Band Saw Machine

320mm Automatic horizontal dual column type band saw which incorporates a massive base, sturdy saw frame, with an extremely heavy-duty gear box, a 3.75kW (5HP) drive motor, a user-friendly programmable control, and a modern new look. The Smart NC-100 technology is programmable up to 100 different jobs including quantity and length of cut with Automatic Multiple Indexing & Automatic Kerf Compensation. Cutting information such as blade speed, down feed speed, cutting rate, blade life and error message is clearly displayed for ease of use.

Standard Features

• 7" HMI Touch Screen & Mitsubishi PLC Controller.
• 100 individual jobs can be programmed and stored.
• Automatic kerf compensation.
• "Save-a-Blade" function.
• Rapid troubleshooting via error feedback system.
• Double retracting vises.
• Scrape-free vise plates.
• Full stroke hydraulic cylinder.
• Split front vises.
• Inverter-controlled infinitely variable blade speed.
• Automatic hydraulic blade tension device.
• Hydraulic Chip Conveyor.
• Vibration Damper.
• Blade Height Decoder.
