320mm Round Automatic Horizontal Dual Column Type Band Saw

Description

Band Saw Machine

320mm Automatic horizontal dual column type band saw incorporates a 5 hp powerful blade motor, 34 (mm) wide blade, independent control panel, and heavy-duty dual column design. These features create a very rigid, dynamically stable and productive machine. The oversized precision ground columns ensure smooth saw frame movement and the consistently stable cutting force required throughout the cutting cycle, thereby increasing the cutting efficiency and extending blade life.

Standard Features

• 7" HMI Touch Screen & Mitsubishi PLC Controller.
• 100 individual jobs can be programmed and stored.
• Automatic kerf compensation.
• "Save-a-Blade" function.
• Rapid troubleshooting via error feedback system.
• Double retracting vises.
• Scrape-free vise plates.
• Full stroke hydraulic cylinder.
• Split front vises.
• Inverter-controlled infinitely variable blade speed.
• Automatic hydraulic blade tension device.
• Hydraulic Chip Conveyor.
• Vibration Damper.
• Blade Height Decoder.
