300mm Round Automatic Horizontal Scissor Type Mitering Band Saw
Have one to sell?
ConditionNew
New
Band Saw Machine
300mm Automatic horizontal scissor type mitering band saw is a high production machine which incorporates a massive base, sturdy saw frame, with an extremely heavy-duty gear box, a 5HP drive motor, and a user-friendly programmable control for ease of operation.
Standard Features
• 7" HMI touch screen.
• The two wheels adopt high-level cast iron and been heat treatment to ensure endurable and long-life.
• Automatic kerf compensation.
• "Save-a-Blade" function.
• Rapid troubleshooting via error feedback system.
• Selector Switch for bundle or single cutting modes.
• Full stroke hydraulic cylinder.
• Ductile cast iron vises with replaceable hardened wear plates.
• Inverter-controlled infinitely variable blade speed.
• Automatic hydraulic blade tension device.
Optional Accessories
• Hydraulic chip conveyor.
• Vise pressure regulator.
• Hydraulic top clamps.
• 2M roller table.
Type Of Saw
Horizontal
Automation
Automatic
Miter
No
Automation Type
SNC
Production Line
Horizontal-Pivot
Capacity-Max. Height (Mm)
≦300
Capacity-Max. Width/Throat (Mm)
≦320
Capacity-Round (Mm)
300
Top Clamp-Min.~Max. Height (Mm)
70~140
Blade / Circular Saw Width (Mm)
34
Blade Speed Min.~Max. (M/Min)
15~100
